Additional information
| Weight | 310 g |
|---|---|
| Dimensions | 77 × 45 × 86 cm |
| Extended Product Type | AF09-30-10-14 |
| Standard | IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60335-2-40 LZGH2 A2L, UL 60947-4-1, CSA C22.2 No. 60335-2-40 LZGH2 A2L, CSA C22.2 No. 60947-4-1 |
| Number of Poles | 3P |
| Rated Current | 35A |
| Rated Voltage | 690V |
| Rated Power | 4kW |
| Rated Frequency | 50/60Hz |
| Breaking Capacity | 100A |
| Frame size | 00 |
| Mounting | TH35-15 (35 x 1.5 cm Mounting Rail) acc. to IEC 60715 |
| Degree of Protection IP | IP20 |
| Mounting Type | TH35-15 (35 x 1.5 cm Mounting Rail) acc. to IEC 60715 |
| Rated Cross-Section | 0.75…6 mm² |
| Terminal type | Screw Terminals |
| Product Net Depth (MM) | 7.7 cm |
| Customs Tariff Number | 85364900 |
| Minimum Order Quantity | 1 |
| Temperature Range | -25…60°C |
| GTIN (EAN) | 3471523110045 |
| resistance | 4 g Closed Position & 2 g Open position 5 … 300 Hz |
| _OG Title | AF09-30-10-14 |
| A2L Certificate – UL | 9AKK108469A4875 |
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| ABS Certificate | ABS_20-2060694-PDA |
| BV Certificate | BV_2634H24898C1 |
| CB Certificate | CB_SE-117714 |
| CCC Certificate | CCC_2024010304656669 |
| CQC Certificate | CQC2010010304445624 |
| Climatic Withstand | Category B according to IEC 60947-1 Annex Q |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Connecting Capacity Auxiliary Circuit | Flexible with Ferrule 1/2x 0.75 … 2.5 mm² |
| Connecting Capacity Auxiliary Circuit UL/CSA | Rigid Solid 1/2x 18-14 AWG |
| Connecting Capacity Control Circuit | Flexible with Ferrule 1/2x 0.75 … 2.5 mm² |
| Connecting Capacity Control Circuit UL/CSA | Rigid Solid 1/2x 18-14 AWG |
| Connecting Capacity Main Circuit UL/CSA | Rigid Solid 1/2x 16-10 AWG |
| Country of Origin | Switzerland |
| DNV Certificate | DNV_TAE00001AF-4 |
| Data Sheet, Technical Information | 1SBC100214C0202 |
| Declaration of Conformity - CCC | 2020980304001253 |
| Declaration of Conformity - CE | 1SBD250000U1000 |
| Declaration of Conformity - UKCA | 1SBD250031U1000 |
| Display Name | AF09-30-10-14 |
| E-Number (Finland) | 3706202 |
| E-Number (Sweden) | 3210011 |
| ETIM 7 | EC000066 – Power contactor, AC switching |
| ETIM 8 | EC000066 – Power contactor, AC switching |
| ETIM 9 | EC000066 – Power contactor, AC switching |
| EcoSolutions Profile | 1SBC100156C0308 |
| End Of Life Disassembling Instructions | 1SBC101080M6801 |
| Environmental Product Declaration - EPD | 1SBD250584E3000 |
| Full Load Amps Motor Use | (120 V AC) Single Phase 13.8 A |
| General Use Rating UL/CSA | (600 V AC) 25 A |
| Horsepower Rating NEMA | (115 V AC) Single Phase 1/3 Hp |
| Horsepower Rating UL/CSA | (120 V AC) Single Phase 3/4 hp |
| IDEA Granular Category Code (IGCC) | 4758 >> Iec Contactors |
| Improved Energy Efficiency for Customers | Product Efficiency – Product considered more energy-efficient compared to similar product on market or older products from the same line |
| Instructions and Manuals | 1SBC101027M6801 |
| Instructions and Manuals (Part 2) | 1SAC200017M0002 |
| KC Certificate | KC_HW02016-15004C |
| LR Certificate | LRS_LR23403517TA-02 |
| Lead Time | 0 day |
| Made To Order | No |
| Maximum Electrical Switching Frequency | (AC-1) 600 cycles per hour |
| Maximum Mechanical Switching Frequency | 3600 cycles per hour |
| Maximum Operating Altitude Permissible | Without Derating 3000 m |
| Maximum Operating Voltage UL/CSA | Main Circuit 600 V |
| Mounting by Screws (not supplied) | 2 x M4 Screws Placed Diagonally |
| Number of Auxiliary Contacts NC | 0 |
| Number of Auxiliary Contacts NO | 1 |
| Number of Main Contacts NC | 0 |
| Number of Main Contacts NO | 3 |
| Object Classification Code | Q |
| Operate Time | Between Coil De-energization and NC Contact Closing 13 … 98 ms |
| Package Level 1 Depth / Length | 7.9 cm |
| Package Level 1 Gross Weight | 310 g |
| Package Level 1 Height | 4.7 cm |
| Package Level 1 Width | 8.7 cm |
| Pollution Degree | 3 |
| Power Loss | at 6 A per Pole 0.1 W |
| Product ID | 1SBL137001R1410 |
| Product Name | Block Contactor |
| Product Sales Status | Active |
| Quote Only | No |
| REACH Declaration | 2CMT2021-006202 |
| RINA Certificate | RINA_ELE142224XG |
| RMRS Certificate | RMRS_1802705280 |
| Rated Control Circuit Voltage (Uc) | 50 Hz 250 … 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-4-1 690 V |
| Rated Operational Current AC-15 (Ie) | (500 V) 2 A |
| Rated Operational Current AC-3e (Ie) | (415 V) 60 °C 9 A |
| Rated Operational Current DC-1 (Ie) | (110 V) 1-Pole, 40 °C 10 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A / 144 W |
| Rated Operational Current DC-3 (Ie) | (110 V) 1-Pole, 40 °C 6 A |
| Rated Operational Current DC-5 (Ie) | (110 V) 1-Pole, 40 °C 4 A |
| Rated Short-time Withstand Current Low Voltage (Icw) | at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 150 A |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops – Standard EN45555 – 92.7 % |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | 93325e0f-b100-4fe0-9087-ea4ba852c6a0 China |
| Simplified SCIP | 2d84fc0c-9822-43bb-ab06-99aa3a5e7024 Sweden |
| Stocked At Warehouses | CHABB001EXPU |
| Tightening Torque | Auxiliary Circuit 1.2 N·m |
| Tightening Torque UL/CSA | Auxiliary Circuit 11 in·lb |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| UL Certificate | UL-US-2150887-5 |
| UL Listing Card | E312527 |
| UNSPSC | 39121529 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Warranty Return | Product under warranty must be returned |
| Wire Stripping Length | Auxiliary Circuit 1 cm |
| eClass | V11.0 : 27371003 |
