Additional information
| Weight | 405 g |
|---|---|
| Dimensions | 65 × 54 × 85 cm |
| Extended Product Type | ESB63-40N-06 |
| Standard | IEC/EN 60947-1 |
| Number of Poles | 4P |
| Rated Current | 63A |
| Rated Voltage | 220VDC |
| Rated Power | 5kW |
| Rated Frequency | 400Hz |
| Mounting | TH35-15 (35 x 1.5 cm Mounting Rail) acc. to IEC 60715 |
| Degree of Protection IP | IP20 |
| Mounting Type | TH35-15 (35 x 1.5 cm Mounting Rail) acc. to IEC 60715 |
| Rated Cross-Section | 1.5…1.6 cm² |
| Terminal type | Screw Terminals |
| Product Net Depth (MM) | 6.5 cm |
| Customs Tariff Number | 85365080 |
| Minimum Order Quantity | 4 |
| Temperature Range | -25…+55°C |
| DIN Place Units | 3 |
| GTIN (EAN) | 4013614520983 |
| resistance | 11 ms Pulse 15 g |
| _OG Title | ESB63-40N-06 |
| A2L Certificate – IEC | 1SAA920000-4601 |
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| ABS Certificate | 1SAA920000-0101 |
| CB Certificate | 1SAA920005-2001 |
| CCC Certificate | 2024010304659840 |
| Coil Consumption | Average Holding Value 50 / 60 Hz 4.5 V·A |
| Coil Operating Limits | (acc. to IEC 60947-4-1) 0.85 … 1.1 x Uc (at θ ≤ 55 °C) |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Connecting Capacity Control Circuit | Flexible with Ferrule 1x 0.75 … 2.5 mm² |
| Connecting Capacity Control Circuit UL/CSA | Solid 16-10 AWG |
| Connecting Capacity Main Circuit UL/CSA | Solid 16-4 AWG |
| DNV Certificate | 1SAA920000-0306 |
| Data Sheet, Technical Information | 2CDC103051C0201 |
| Declaration of Conformity - CE | 1SAD101100-3301 |
| Declaration of Conformity - UKCA | 1SAD201100-3301 |
| Display Name | ESB63-40N-06 |
| ETIM 7 | EC001653 – Installation contactor for distribution board |
| ETIM 8 | EC001653 – Installation contactor for distribution board |
| ETIM 9 | EC001653 – Installation contactor for distribution board |
| EcoSolutions Profile | 1SFC100125C0336 |
| Electrical Durability | AC-1 (NO) 100000 cycle |
| End Of Life Disassembling Instructions | 1SBC100156C0266 |
| Environmental Product Declaration - EPD | 1SAC200433H0001 |
| Full Load Amps Motor Use | (220 … 240 V AC) Single Phase, NO 28 A |
| General Use Rating UL/CSA | (acc. to UL 240 V) 63 A |
| Horsepower Rating UL/CSA | (220 … 240 V AC) Single Phase, NO 5 Hp |
| IDEA Granular Category Code (IGCC) | 4759 >> Installation contactor for distribution board |
| Improved Energy Efficiency for Customers | Product Efficiency – Product considered more energy-efficient compared to similar product on market or older products from the same line |
| Instructions and Manuals | 2CDC103043M6801 |
| Maximum Electrical Switching Frequency | (AC-1) 300 cycles per hour |
| Maximum Operating Altitude Permissible | 2000 m |
| Maximum Operating Voltage UL/CSA | Main Circuit 480 V AC |
| Mechanical Durability | Nr. Operations 1000000 cycle |
| NF Certificate | 1SAA920001-1202 |
| Number of Auxiliary Contacts NC | 0 |
| Number of Auxiliary Contacts NO | 0 |
| Number of Main Contacts NC | 0 |
| Number of Main Contacts NO | 4 |
| Object Classification Code | Q |
| Package Level 1 Depth / Length | 22.2 cm |
| Package Level 1 Gross Weight | 1.62 kg |
| Package Level 1 Height | 6.95 cm |
| Package Level 1 Width | 8.8 cm |
| Package Level 2 EAN | 4013614568374 |
| Pollution Degree | 3 |
| Power Loss | at Rated Operating Conditions AC-1 per Pole 4.5 W |
| Product ID | 1SAE351111M0640 |
| Product Name | Installation Contactor |
| REACH Declaration | 2CMT2021-006202 |
| RINA Certificate | 1SAA920000-0801 |
| Rated Breaking Capacity AC-3 | 8 x Ie / AC-3 |
| Rated Control Circuit Voltage (Uc) | 230 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | 500 V |
| Rated Making Capacity AC-3 | 10 x Ie / AC-3 |
| Rated Operational Current AC-7a (Ie) | (NO) 63 A |
| Rated Operational Current AC-7b (Ie) | (230 V) Single Phase, NO 30 A |
| Rated Operational Power AC-7a (Pe) | (230 V) Single Phase, NO 14.5 kW |
| Rated Operational Power AC-7b (Pe) | (230 V) Single Phase, NO 5 kW |
| Rated Short-time Withstand Current Low Voltage (Icw) | at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 240 A |
| Recommended Screw Driver | Control Circuit Pozidriv 1 |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops – Standard EN45555 – 94.1 % |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Tightening Torque | Control Circuit 0.9 N·m |
| Tightening Torque UL/CSA | Control Circuit 8 in·lb |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| UL Certificate | E191658-19960301 |
| UNSPSC | 39121529 |
| WEEE B2C / B2B | Business To Consumer |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Wire Stripping Length | Control Circuit 7 mm |
| eClass | V11.0 : 27142308 |
