Additional information
| Weight | 250 g |
|---|---|
| Dimensions | 72.5 × 52.5 × 91.5 cm |
| Extended Product Type | OT80F3 |
| Standard | IEC 60947-3 / UL 508 / CSA C22.2 No. 14 |
| Number of Poles | 3P |
| Rated Current | 80A |
| Rated Voltage | 750V |
| Mounting | Base mounting |
| Row Spacing | Standard |
| Degree of Protection IP | IP20 |
| Mounting Type | Base mounting |
| Rated Cross-Section | 1.5…3.5 cm² |
| Terminal type | Screw Terminals |
| Product Net Depth (MM) | 7.25 cm |
| Customs Tariff Number | 85365080 |
| Minimum Order Quantity | 10 |
| Operating mode | Front |
| GTIN (EAN) | 6417019397016 |
| _OG Title | OT80F3 |
| A2L Certificate – IEC | 1SCC301335D0201 |
| ATEX Certificate | No certification needed |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Country of Origin | Finland |
| Data Sheet, Technical Information | 1SCC301020C0201 |
| Declaration of Conformity - CE | 1SCC301167D2704 |
| Display Name | OT80F3 |
| E-Number (Finland) | 3601458 |
| E-Number (Norway) | 4363528 |
| E-Number (Sweden) | 3170941 |
| ETIM 10 | EC000216 – Switch disconnector (AC) |
| ETIM 9 | EC000216 – Switch disconnector (low voltage) |
| Environmental Information | 1SCC301263D0201 |
| Environmental Product Declaration - EPD | 1SCC301279D0201 |
| Handle Type | Knob |
| Horsepower Rating UL/CSA | (110 … 120 V AC) Single Phase 2 Hp |
| IDEA Granular Category Code (IGCC) | 5290 >> Disconnect switch |
| Instructions and Manuals | 1SCC301064M0212 |
| Maximum Operating Voltage UL/CSA | 600 V |
| Mechanical Durability | 20000 |
| Object Classification Code | Q |
| Package Level 1 Depth / Length | 10.3 cm |
| Package Level 1 Gross Weight | 270 g |
| Package Level 1 Height | 6.4 cm |
| Package Level 1 Width | 8.4 cm |
| Pollution Degree | 3 |
| Position of Line Terminals | Top In – Bottom Out |
| Power Loss | at Rated Operating Conditions per Pole 4.5 W |
| Product ID | 1SCA105798R1001 |
| REACH Declaration | 1SCC011021D0201 |
| Rated Conditional Short-Circuit Current (Inc) | (100 A fuse, ≤415 V) 50 kA |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 750 V |
| Rated Operational Current AC-21A (Ie) | (380 … 415 V) 80 A |
| Rated Operational Current AC-22A (Ie) | (380 … 415 V) 80 A |
| Rated Operational Current AC-23A (Ie) | (380 … 415 V) 75 A |
| Rated Operational Power AC-23A (Pe) | (220 … 240 V) 22 kW |
| Rated Short-Circuit Making Capacity (Icm) | (690 V) 2.1 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 1.5 kA |
| Recommended Screw Driver | Main Circuit Pozidriv 2 |
| RoHS Declaration | 1SCC011020D0201 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Special Functions | No |
| Switches Operating Mechanism | Mechanism on Top of the Switch |
| Tightening Torque | acc. IEC 60947-1 2 N·m |
| Tightening Torque UL/CSA | 18 in·lb |
| Toxic Substances Control Act - TSCA | 1SCC011025D0201 |
| UL Certificate | cULus certificate OT16-80 |
| UNSPSC | 39122233 |
| VDE Certificate | No certification needed |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Wire Stripping Length | Main Circuit 10-1.2 cm |
| eClass | V11.1 : 27371403 |
