Additional information
| Weight | 15.57 kg |
|---|---|
| Extended Product Type | OXB200E3S2QT |
| Standard | IEC60947-6-1 |
| Number of Poles | 4P |
| Rated Current | 200A |
| Rated Voltage | 480VAC |
| Rated Frequency | 60Hz |
| Degree of Protection IP | IP20 |
| Terminal type | Bolt |
| Product Net Depth (MM) | 18.3 cm |
| Customs Tariff Number | 85365080 |
| Minimum Order Quantity | 1 |
| GTIN (EAN) | 6.41702E+12 |
| L1 | Electrical |
| L2 | Power Distribution |
| L3 | Transfer Switches |
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Controller Type | Level 2 (DIP) |
| Extended Product Lifetime | Product Modularity |
| Fourth Pole Position | Left and Right Side |
| Fourth Pole Type | Switched – Simultaneous Function |
| Handle Type | Direct Mount |
| Package Level 1 Depth / Length | 44.5 cm |
| Package Level 1 Gross Weight | 16.27 kg |
| Package Level 1 Height | 24 cm |
| Package Level 1 Width | 34.5 cm |
| Pollution Degree | 3 |
| Position of Line Terminals | Supplies on Top – Load on Bottom |
| Power Loss | at Rated Operating Conditions per Pole 5.8 W |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Current AC-31B (Ie) | (200 … 415 V AC) 200 A |
| Rated Operational Current AC-32B (Ie) | (200 … 415 V AC) 200 A |
| Rated Operational Current AC-33B (Ie) | (200 … 415 V AC) 200 A |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 0.3 s 18 kiloampere rms |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops – Standard EN45555 – 67.3 % |
| Special Functions | Open style |
| Transition Type | Delayed |
