Additional information
| Weight | 2.11 kg |
|---|---|
| Dimensions | 13.1 × 28.6 × 10.3 cm |
| Extended Product Type | OTM63F4CB21D400C |
| Number of Poles | 4P |
| Rated Current | 63A |
| Rated Voltage | 415V |
| Mounting | Base Mounting Or DIN-rail mounting |
| Degree of Protection IP | IP20 |
| Mounting Type | Base Mounting Or DIN-rail mounting |
| Terminal Type | Screw Terminals |
| Product Net Depth (MM) | 13.1 cm |
| Customs Tariff Number | 85365080 |
| Minimum Order Quantity | 1 |
| GTIN (EAN) | 6.41702E+12 |
| L1 | |
| L2 | Power Distribution |
| L3 | Transfer Switches |
| Controller Type | 21D |
| Country of Origin | China |
| Fourth Pole Type | Switched – Simultaneous Function |
| Handle Type | Direct Mount |
| Motor Operational Voltage | 380…415 V AC |
| Package Level 1 Depth / Length | 32.8 cm |
| Package Level 1 Gross Weight | 2.35 kg |
| Package Level 1 Height | 16.8 cm |
| Package Level 1 Width | 10.3 cm |
| Pollution Degree | 3 |
| Position of Line Terminals | Supplies on Bottom – Load on Top |
| Power Loss | at Rated Operating Conditions per Pole 2.8 W |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 800 V |
| Rated Operational Current AC-21A (Ie) | (380 … 415 V) 63 A |
| Rated Operational Current AC-22A (Ie) | (380 … 415 V) 63 A |
| Rated Operational Current AC-23A (Ie) | (380 … 415 V) 63 A |
| Rated Operational Current AC-31B (Ie) | (380 … 415 V) 63 A |
| Rated Operational Current AC-32B (Ie) | (380 … 415 V) 63 A |
| Rated Operational Current AC-33B (Ie) | (380 … 415 V) 63 A |
| Rated Operational Power AC-23A (Pe) | (380 … 415 V) 30 kW |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 2.5 kiloampere rms |
| Tightening Torque | acc. IEC 60947-1 6 N·m |
| Transition Type | Open |
