Additional information
| Weight | 370 g |
|---|---|
| Dimensions | 6.5 × 5.4 × 8.5 cm |
| Extended Product Type | ESB40-20N-06 |
| Standard | IEC/EN 60947-1 |
| Number of Poles | 2P |
| Rated Current | 40A |
| Rated Voltage | 220VDC |
| Rated Power | 3.7kW |
| Rated Frequency | 400Hz |
| Mounting | TH35-15 (35 x 1.5 cm Mounting Rail) acc. to IEC 60715 |
| Degree of Protection IP | IP20 |
| Mounting Type | TH35-15 (35 x 1.5 cm Mounting Rail) acc. to IEC 60715 |
| Rated Cross-Section | 1.5…1.6 cm² |
| Terminal Type | Screw Terminals |
| Product Net Depth (MM) | 6.5 cm |
| Customs Tariff Number | 85365080 |
| Minimum Order Quantity | 4 |
| Temperature Range | -25…+55°C |
| DIN Place Units | 3 |
| GTIN (EAN) | 4.01361E+12 |
| Resistance | 11 ms Pulse 15 g |
| L1 | |
| L2 | Switchgear & Contactors |
| L3 | Contactors |
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| Coil Consumption | Average Holding Value 50 / 60 Hz 4.5 V·A |
| Coil Operating Limits | (acc. to IEC 60947-4-1) 0.85 … 1.1 x Uc (at θ ≤ 55 °C) |
| Connecting Capacity Control Circuit | Flexible with Ferrule 1x 0.75 … 2.5 mm² |
| Connecting Capacity Control Circuit UL/CSA | Solid 16-10 AWG |
| Connecting Capacity Main Circuit UL/CSA | Solid 16-4 AWG |
| Electrical Durability | AC-1 (NO) 150000 cycle |
| Full Load Amps Motor Use | (220 … 240 V AC) Single Phase, NO 22 A |
| General Use Rating UL/CSA | (acc. to UL 240 V) 40 A |
| Horsepower Rating UL/CSA | (220 … 240 V AC) Single Phase, NO 3 Hp |
| Improved Energy Efficiency for Customers | Product Efficiency – Product considered more energy-efficient compared to similar product on market or older products from the same line |
| Maximum Electrical Switching Frequency | (AC-1) 300 cycles per hour |
| Maximum Operating Altitude Permissible | 2000 m |
| Maximum Operating Voltage UL/CSA | Main Circuit 480 V AC |
| Mechanical Durability | Nr. Operations 1000000 cycle |
| Number of Auxiliary Contacts NC | 0 |
| Number of Auxiliary Contacts NO | 0 |
| Number of Main Contacts NC | 0 |
| Number of Main Contacts NO | 2 |
| Package Level 1 Depth / Length | 22.2 cm |
| Package Level 1 Gross Weight | 1.48 kg |
| Package Level 1 Height | 6.95 cm |
| Package Level 1 Width | 8.8 cm |
| Pollution Degree | 3 |
| Power Loss | at Rated Operating Conditions AC-1 per Pole 3 W |
| Product Name | Installation Contactor |
| Rated Breaking Capacity AC-3 | 8 x Ie / AC-3 |
| Rated Control Circuit Voltage (Uc) | 230 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | 500 V |
| Rated Making Capacity AC-3 | 10 x Ie / AC-3 |
| Rated Operational Current AC-7a (Ie) | (NO) 40 A |
| Rated Operational Current AC-7b (Ie) | (230 V) Single Phase, NO 22 A |
| Rated Operational Power AC-7a (Pe) | (230 V) Single Phase, NO 9.2 kW |
| Rated Operational Power AC-7b (Pe) | (230 V) Single Phase, NO 3.7 kW |
| Rated Short-time Withstand Current Low Voltage (Icw) | at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 176 A |
| Recommended Screw Driver | Control Circuit Pozidriv 1 |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops – Standard EN45555 – 94.1 % |
| Tightening Torque | Control Circuit 0.9 N·m |
| Tightening Torque UL/CSA | Control Circuit 8 in·lb |
| Wire Stripping Length | Control Circuit 7 mm |
