Description
ZS4-RD
Entrelec ZS4 screw-clamp feed-through terminal block rated 4 mm² (12 AWG) at 5.2 mm pitch, 32 A (UL 20 A) / 1000 V (UL 600 V). Single-level, two screw clamps connecting one or two conductors per side (Rigid 0.2-4 mm² / Flexible 0.22-4 mm² (24-12 AWG)). Mounts on TH35 (EN 50022) DIN rail; body colour red. Standards IEC 60947-7-1; UL 1059; CSA C22.2 No.158. Impulse withstand 8000 V.
Key features
- Rated cross-section: 4 mm² (12 AWG)
- Connection capacity: Rigid 0.2-4 mm² / Flexible 0.22-4 mm² (24-12 AWG)
- Rated voltage Ui: 1000 V (UL 600 V)
- Rated current: 32 A (UL 20 A)
- Impulse withstand voltage: 8000 V
- Connection technology: Screw clamp
Full technical specifications are listed under Additional Information. Datasheet (PDF). Source: Entrelec Terminal Blocks SNK catalog.
