Additional information
| Weight | 400 g |
|---|---|
| Dimensions | 11.4 × 4.5 × 14 cm |
| Extended Product Type | PSR16-600-70 |
| Rated Voltage | 600VAC |
| Rated Power | 4kW |
| Rated Frequency | 50/60Hz |
| Trip Unit | No |
| Application | Soft start with voltage ramp |
| Degree of Protection IP | IP20 |
| Communication | FiledBusPlug(Optional) |
| Rated Cross-Section | 0.75…2.5 mm² |
| Terminal Type | Screw Terminals |
| Product Net Depth (MM) | 11.4 cm |
| Customs Tariff Number | 85371091 |
| Minimum Order Quantity | 1 |
| Protection | Recommended MS132 10.00 … 16.00 |
| Temperature Range | -25…+60°C |
| GTIN (EAN) | 7.3205E+12 |
| Inrush current | 4xIe for 6s |
| L1 | |
| L2 | Switchgear & Contactors |
| L3 | Soft Starters |
| By-pass Signal Relay | No |
| Connecting Capacity Control Circuit | 1 x 0.75 … 2.5 mm² |
| Connecting Capacity Supply Circuit | Rigid 1/2 x 0.75 … 2.5 |
| Country of Origin | Sweden |
| Criticality | No |
| Current Limit Function | No |
| Fault Signal Relay | No |
| Horsepower Rating UL/CSA | (200 … 208 V AC) Three Phase 3 Hp |
| Initial Voltage During Start | 40 … 70 % |
| Maximum Operating Voltage UL/CSA | Main Circuit 600 V |
| Note | No |
| Number of Starts Per Hour at 3.5*Ie for 7 sec. 50% ON Time 50% OFF Time | 10 |
| Overload Signal Relay | No |
| Package Level 1 Depth / Length | 5 cm |
| Package Level 1 Gross Weight | 500 g |
| Package Level 1 Height | 15.6 cm |
| Package Level 1 Width | 12.1 cm |
| Ramp Time | 0 … 20 s |
| Rated Control Circuit Voltage (Uc) | 24 V DC |
| Rated Control Supply Voltage (Us) | 100 … 240 V AC |
| Rated Operational Current - In-Line Connection (Ie) | 16 A |
| Run Signal Relay | Yes |
| Service Factor Percentage | 100% |
| Signal Indication Completed Start Ramp (LED) | Green |
| Signal Indication Ramping Up/Down (LED) | Green |
| Signal Indication Ready to Start/Standby ON (LED) | Green |
| Signal Indication Running R (LED) | Green |
| Step Down Voltage Special Ramp | 100 … 60 % |
| Switch for Inside Delta Connection | No |
| Tightening Torque | Control Circuit 1 N·m |
| Tightening Torque UL/CSA | Control Circuit 8.9 in·lb |
