100.06 AED
LS30P13B11 Limit Switch
Bulk Pricing
| Quantity | Price |
|---|---|
| 1 - 5 | 100.06 AED |
| 6 - 10 | 98.06 AED |
| 11 - 50 | 96.06 AED |
| 51 - 200 | 94.06 AED |
| 200+ | 92.06 AED |
In stock
LS30P13B11 is a 3 cm wide, standard Limit Switch made of fiber-glass reinforced UL-V0 material, with 2 mounting holes at the top, 1 Pg13.5 cable entry on the bottom, plastic roller plunger actuator and 1 N.O + 1 N.C snap action (Zb type) contacts
| Weight | 64 g |
|---|---|
| Extended Product Type | LS30P13B11 |
| Rated Current | 10A |
| Rated Frequency | 50/60Hz |
| Degree of Protection IP | IP65 |
| Rated Cross-Section | 1.4 cm² |
| Product Net Depth (MM) | 3 cm |
| Customs Tariff Number | 85364900 |
| Minimum Order Quantity | 10 |
| Temperature Range | -25…+70°C |
| GTIN (EAN) | 3471522006677 |
| Resistance | 25 ms |
| Contact type | Zb |
| Action Type of the Contact Element (acc. to IEC 60947-5-1) | Snap Action Contacts |
| Actuating Force | Minimum Force acc. to IEC 60947-5-1 12 N |
| Actuation Speed | acc. to IEC 60947-5-1 Max. 30 cm/s |
| Actuator Type | plastic roller plunger |
| Angular Head Adjustment | adjustable head every 90° |
| Angular Lever Adjustment | none |
| B10d Value | Operations 30 Millions |
| Climatic Withstand | according to IEC 68-2-3 and Salty Mist according to IEC 68-2-11 |
| Connecting Terminals (delivered in open position) | M3.5 (+, -) pozidriv 2 screw with cable clamp |
| Consistency (Measured over 1 Million Operations) | 0.1 mm |
| Electrical Shock Protection acc. to IEC 536 | Double insulation – Class II |
| Flammability According to UL94 | V-0 |
| Maximum Electrical Switching Frequency | 3600 cycles per hour |
| Mechanical Durability | 10 million |
| Mounting by Screws (not supplied) | 2 x M4 Screws |
| Movement to be Detected | On end or 30° Cam Translation |
| Number and Type of Bottom Cable Glands | Pg 13, 5 Cable Gland |
| Number of Auxiliary Contacts NC | 1 |
| Number of Auxiliary Contacts NO | 1 |
| Operating Head Shape | C shape acc. EN 50047 |
| Package Level 1 Depth / Length | 3.2 cm |
| Package Level 1 Gross Weight | 74 g |
| Package Level 1 Height | 9.5 cm |
| Package Level 1 Width | 3.5 cm |
| Pilot Duty UL/CSA | A600 |
| Positive Opening Operation Force (Direct Opening Action) | Minimum Force acc. to IEC 60947-5-1 41 |
| Positive Opening Operation of NC Contact(s) | Yes |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 500 V |
| Rated Operational Current AC-15 (Ie) | (230 V AC) 3.1 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A |
| Short-Circuit Protective Devices | gG Type Fuses 10 A |
| Terminal Marking | according to EN 50013 |
