Additional information
| Weight | 14 g |
|---|---|
| Dimensions | 2.9 × 1.27 × 1.57 cm |
| Extended Product Type | CR-P024AC1 |
| Standard | IEC/EN 61810-1 |
| Rated Voltage | 400VAC |
| Mounting | 1 |
| Application | Pluggable pcb interface relay CR-P |
| Degree of Protection IP | IP67 |
| Terminal Type | Soldering Pins |
| Product Net Depth (MM) | 2.9 cm |
| Customs Tariff Number | 85364900 |
| Minimum Order Quantity | 10 |
| Temperature Range | -40…+70°C |
| GTIN (EAN) | 4.01361E+12 |
| L1 | |
| L2 | Safety & Machine Guarding |
| L3 | Safety Relays & Controllers |
| Contact Rating UL/CSA | B300 |
| Flammability According to UL94 | V-0 |
| Maximum Operating Altitude Permissible | Without Derating 2000 m |
| Maximum Operating Voltage UL/CSA | 300 V AC |
| Output | 1 C/O (SPDT) Contact |
| Output Signal | 250 V / 16 A |
| Package Level 1 Depth / Length | 1.7 cm |
| Package Level 1 Gross Weight | 157 g |
| Package Level 1 Height | 2.8 cm |
| Package Level 1 Width | 33.2 cm |
| Pilot Duty UL/CSA | B300 |
| Rated Control Supply Voltage (Us) | 24 V AC |
| Rated Insulation Voltage (Ui) | 400 V |
| Rated Operational Current AC-12 (Ie) | (230 V) 16 A |
| Rated Operational Current AC-15 (Ie) | (120 V) 3 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 16 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 2.5 A |
| Sub-Function | Relay w/o built in LED |
