Additional information
| Weight | 65 g |
|---|---|
| Dimensions | 9.84 × 3.06 × 4.25 cm |
| Extended Product Type | CR-M4LP |
| Standard | CAN/CSA C22.2 No.14 |
| Rated Voltage | 250V |
| Mounting | 1 |
| Application | Accessory for interface relays CR-M |
| Terminal Type | Push-in Spring Terminals |
| Product Net Depth (MM) | 9.84 cm |
| Customs Tariff Number | 85366990 |
| Minimum Order Quantity | 10 |
| Temperature Range | -40…+70°C |
| GTIN (EAN) | 4.05355E+12 |
| L1 | Automation & Control |
| L2 | Safety & Machine Guarding |
| L3 | Safety Relays & Controllers |
| Connecting Capacity Main Circuit UL/CSA | Flexible with Ferrule 2x 20-17 AWG |
| Flammability According to UL94 | V-0 |
| Maximum Operating Altitude Permissible | 2000 m |
| Output Signal | 250 V / 6 A |
| Package Level 1 Depth / Length | 16.2 cm |
| Package Level 1 Gross Weight | 704 g |
| Package Level 1 Height | 8.7 cm |
| Package Level 1 Width | 10.4 cm |
| Rated Insulation Voltage (Ui) | 2000 V |
| Recommended Screw Driver | 2.5 |
| Sub-Function | Socket for miniature relays |
| Sub-Function 2 | Logical socket for miniature relay 2 c/o or 4 c/o |
| Wire Stripping Length | 1 cm |
