Description
D95/26
Entrelec D95/26 spring-clamp feed-through power terminal block, 95 mm² at 2.6 cm pitch, rated ~232 A / 1000 V IEC. Screwless spring connection for large conductors. Grey polyamide, TH35 rail. Standards IEC 60947-7-1; UL 1059; CSA C22.2 No.158.
Key features
- Rated cross-section: 95 mm² (4/0 AWG)
- Rated current: ~232 A
- Rated voltage Ui: 1000 V (UL 600 V)
- Connection technology: Spring clamp, screwless
- Pitch / spacing: 2.6 cm
- Mounting rail: TH 35-7.5 / TH 35-15 (EN 50022)
Full technical specifications are listed under Additional Information. Datasheet (PDF). Source: Entrelec Terminal Blocks M-series catalog (some specifications are indicative — verify against the datasheet).
