Additional information
| Weight | 27 g |
|---|---|
| Color | black |
| Contact type | 1 NO contact (Triac (zero-cross switch)) |
| Degree of Protection IP | IP20 |
| Execution Type | 27-37-16-04 |
| Inrush current | 15 A / 10 ms |
| L1 | |
| L2 | Semiconductors |
| L3 | Optocouplers & Photocouplers |
| Minimum Order Quantity | 10 |
| Mounting | TS 35 |
| Product Type | Optocoupler |
| Protection | 2 |
| Rated Cross-Section | 0.14 mm² Р2.5 mm² |
| Rated Current | 1A |
| Rated Residual Current | 1mA |
| Rated Voltage | 240V |
| Row Spacing | 9 mm |
| Setting range | 9 mm |
| Surge protection | 6 kV (1.2/50 µs) |
| Temperature Range | -20C…60C |
| Terminal Type | PUSH IN |
