Additional information
| Weight | 56 g |
|---|---|
| Application | IP20 without connected conductor at complete opened clamping yoke connection. |
| Color | black |
| Contact type | 2 CO contact (AgNi) |
| Degree of Protection IP | IP20 |
| Execution Type | 27-37-16-01 |
| Inrush current | 15 A / 4 s |
| L1 | Electronic Components |
| L2 | Switches & Relays |
| L3 | DPDT), PCB Mount Relays (SPDT |
| Minimum Order Quantity | 10 |
| Mounting | TS 35 |
| Product Type | Switching relay |
| Protection | 2 |
| Rated Cross-Section | 1 mm² Р2.5 mm² |
| Rated Current | 8A |
| Rated Residual Current | 8mA |
| Rated Voltage | 250V |
| Row Spacing | 8 mm |
| Setting range | 8 mm |
| Surge protection | 5 kV (1.2/50 µs) |
| Temperature Range | -40C…70C |
| Terminal Type | Screw connection |
