Additional information
| Weight | 900 g |
|---|---|
| Dimensions | 9 × 14.5 × 20 cm |
| Extended Product Type | OTP63B3 m |
| Standard | -3, IEC 60947-1 |
| Number of Poles | 3P |
| Rated Current | 80A |
| Rated Voltage | 750V |
| Material | Plastic |
| Color | RAL7035 |
| Degree of Protection IP | IP65 |
| Rated Cross-Section | 1.5…3.5 cm² |
| Product Net Depth (MM) | 9 cm |
| Customs Tariff Number | 85363030 |
| Minimum Order Quantity | 1 |
| GTIN (EAN) | 6.41702E+12 |
| Resistance | Housing IK08 |
| L1 | |
| L2 | Switchgear & Contactors |
| L3 | Disconnect Switches |
| Cable Entry Position | Top/Bottom |
| Cable Outlets Per Side | 2xM32+M16 / 2xM32+M16 |
| Country of Origin | Finland |
| Handle Type | Selector |
| Maximum Mounted Auxiliary Contacts | 2 NO, 2 NC |
| Mounted Auxiliary Contacts | 0 NO, 0 NC |
| Neutral Type | Fixed Neutral |
| Number of Auxiliary Contacts NC | 0 |
| Number of Auxiliary Contacts NO | 0 |
| Package Level 1 Depth / Length | 22.2 cm |
| Package Level 1 Gross Weight | 1 kg |
| Package Level 1 Height | 14.8 cm |
| Package Level 1 Width | 16.2 cm |
| Pollution Degree | 3 |
| Position of Line Terminals | Top In – Bottom Out |
| Position of Neutral Terminals | Top In – Bottom Out |
| Position of PE Terminals | Top In – Bottom Out |
| Power Loss | at Rated Operating Conditions per Pole 2.8 W |
| Rated Impulse Withstand Voltage (Uimp) | 1.5 kV |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 750 V |
| Rated Operational Current AC-21A (Ie) | (500 V) 80 A |
| Rated Operational Current AC-22A (Ie) | (380 … 415 V) 80 A |
| Rated Operational Current AC-23A (Ie) | (380 … 415 V) 75 A |
| Rated Operational Power AC-23A (Pe) | (380 … 415 V) 37 kW |
| Rated Short-Circuit Making Capacity (Icm) | (690 V AC) 2.1 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 1.5 kA |
| Recommended Screw Driver | Main Circuit Pozidriv 2 |
| Tightening Torque | Main Circuit 2 N·m |
| Wire Stripping Length | 1.3 cm |
