Description
Switch-disconnector fuse, 125A, 4-pole, DIN,000/00, front operated, switched fusible fourth pole, mounting instruction and line/load labels not included.
OS125GD40F-134
573.00 AED
OS125GD40F-134 SWITCH FUSE
Not held in stock. We order it from the manufacturer, and the lead time — about 2 months on average — starts once they confirm the order.Subject to the manufacturer's final confirmation.
Bulk Pricing
| Quantity | Price |
|---|---|
| 1 - 5 | 573.00 AED |
| 6 - 10 | 561.54 AED |
| 11 - 50 | 550.08 AED |
| 51 - 200 | 538.62 AED |
| 200+ | 527.16 AED |
Out of stock
- Free delivery in the UAE over 150.00 AED, worldwide over 5,000.00 AED
- Prices exclude VAT — VAT is shown at checkout, and exports are zero‑rated
- 15 days to return it if it is not right
- Need project or volume pricing? Use Add to Quote and our team will price it
Description
Additional information
Additional information
| Weight | 2.4 kg |
|---|---|
| Extended Product Type | OS125GD40F-134 |
| Standard | IEC 60947-3 |
| Number of Poles | 4P |
| Rated Current | 125A |
| Rated Voltage | 690VAC |
| Mounting | Base mounting |
| Fuse system | DIN |
| Degree of Protection IP | IP20 |
| Mounting Type | Base mounting |
| Terminal Type | Lug terminals |
| Customs Tariff Number | 85365080 |
| Minimum Order Quantity | 1 |
| Operating mode | Front |
| GTIN (EAN) | 6417019893211 |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Country of Origin | Finland |
| Fourth Pole Type | Switched – Fusible Pole |
| Handle Type | Handle Not Included |
| Package Level 1 Depth / Length | 22 cm |
| Package Level 1 Gross Weight | 2.55 kg |
| Package Level 1 Height | 15 cm |
| Package Level 1 Width | 17 cm |
| Power Loss | at Rated Operating Conditions per Pole 4 W |
| Rated Conditional Short-Circuit Current (Inc) | (500 V) 100 kA |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Power AC-23A (Pe) | (220 … 240 V) 37 kW |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 5 kiloampere rms |
| Switches Operating Mechanism | 40 (Right Side) |
| Tightening Torque | 15 … 22 N·m |
