Additional information
| Weight | 560 g |
|---|---|
| Dimensions | 6 × 11.1 × 13 cm |
| Extended Product Type | KSE425TPSN |
| Standard | -3, IEC 60947-1 |
| Number of Poles | 4P |
| Rated Current | 32A |
| Rated Voltage | 690V |
| Material | Aluminium |
| Color | RAL7012 / RAL7035 |
| Degree of Protection IP | IP65 |
| Rated Cross-Section | 0.75…1 cm² |
| Terminal Type | Screw Terminals |
| Product Net Depth (MM) | 6 cm |
| Customs Tariff Number | 85363030 |
| Minimum Order Quantity | 1 |
| GTIN (EAN) | 7.3927E+12 |
| Resistance | Housing IK09 |
| L1 | |
| L2 | Switchgear & Contactors |
| L3 | Disconnect Switches |
| Cable Entry Position | Top/Bottom |
| Cable Outlets Per Side | 2xM25 / 2xM25 |
| Country of Origin | Bulgaria |
| Handle Type | Side-Operated |
| Maximum Mounted Auxiliary Contacts | 1 NO, 0 NC |
| Mounted Auxiliary Contacts | 0 NO, 0 NC |
| Neutral Type | Switchable Neutral |
| Number of Auxiliary Contacts NC | 0 |
| Number of Auxiliary Contacts NO | 0 |
| Package Level 1 Depth / Length | 13.1 cm |
| Package Level 1 Gross Weight | 560 g |
| Package Level 1 Height | 6.2 cm |
| Package Level 1 Width | 11.2 cm |
| Power Loss | at Rated Operating Conditions per Pole 0.6 W |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 690 V |
| Rated Operational Current AC-22A (Ie) | (380 … 415 V) 25 A |
| Rated Operational Current AC-23A (Ie) | (380 … 415 V) 16 A |
| Rated Operational Power AC-23A (Pe) | (380 … 415 V) 7.5 kW |
| Rated Short-Circuit Making Capacity (Icm) | (690 V AC) 0.71 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 0.5 kA |
| Recommended Screw Driver | Main Circuit Pozidriv 2 |
| Tightening Torque | Main Circuit 1.2 N·m |
| Wire Stripping Length | 7 mm |
