Additional information
| Dimensions | 400 × 132 × 6.1 m |
|---|---|
| Extended Product Type | EMC-S402 S |
| Rated Current | 125A |
| Material | Steel |
| Color | Grey |
| Mounting | Surface mounting |
| Door Type | Panel Door |
| Degree of Protection IP | IP41 |
| Mounting Type | Surface mounting |
| Product Net Depth (MM) | 40 cm |
| Protection | Isolated (Class II) |
| GTIN (EAN) | 6221115064471 |
| resistance | IK07 |
| _OG Title | EMC-S402 S |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| Cover Plate Type | Door |
| Cover Style | Closed |
| Data Sheet, Technical Information | 1SKC802015C0205 |
| Display Name | EMC-S402 S |
| ETIM 10 | EC000058 – Empty cabinet |
| ETIM 9 | EC000058 – Empty cabinet |
| Instructions and Manuals | 1SKC802015C0205 |
| Number of Conduit Inlets | 0 |
| Number of Modules | 18 |
| Product ID | 1SKM304021C0402 |
| REACH Date | 20240129 |
| REACH Declaration | 1SKC910033C0001 |
| REACH Information | False – does not contain substances > 0.1 mass percentage |
| RoHS Date | 20240129 |
| RoHS Declaration | 1SKC910042C0001 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Surface Finishing | Powder coating |
| Thickness | Cabinet Plate 1 mm |
| WEEE Category | Product Not in WEEE Scope |
| eClass | V11.0 : 27142408 |
